* 1/3-2 HP
* 3600, 1800, and 1200 RPM
* High starting torque
* 208-230/460 volt
* Three phase
* 1.15 service factor
* Class F insulation
* Design B
* Continuous duty, 40℃ ambient
* V-ring slinger in both endshields
* Squirrel cage rotor
MODEL NUMBER | HP | RPM | VOLTAGE | FRAME | ENCLOSURE | WEIGHT | DETAILED INFO | LIST PRICE |
CRSTF36-056-13 | 1/3 | 3600 | 208-230/460V | 56C | TEFC | 26 | Detailed information | LOGIN TO SEE |
CRSTF36-056-34 | 3/4 | 3600 | 208-230/460V | 56C | TEFC | 33 | Detailed information | LOGIN TO SEE |
CRSTF36-056-01 | 1 | 3600 | 208-230/460V | 56C | TEFC | 35 | Detailed information | LOGIN TO SEE |
CRSTF18-056-12 | 1/2 | 1800 | 208-230/460V | 56C | TEFC | 29 | Detailed information | LOGIN TO SEE |
CRSTF18-056-13 | 1/3 | 1800 | 208-230/460V | 56C | TEFC | 27 | Detailed information | LOGIN TO SEE |
CRSTF18-056-14 | 1/4 | 1800 | 208-230/460V | 56C | TEFC | 25 | Detailed information | LOGIN TO SEE |
CRSTF18-056-34 | 3/4 | 1800 | 208-230/460V | 56C | TEFC | 33 | Detailed information | LOGIN TO SEE |
CRSTF18-056-15 | 1 1/2 | 1800 | 208-230/460V | 56C | TEFC | 84 | Detailed information | LOGIN TO SEE |
CRSTFIR36-056-12 | 1/2 | 3600 | 208-230/460V | 56C | TEFC | 28 | Detailed information | LOGIN TO SEE |
CRSTFIR36-056-13 | 1/3 | 3600 | 208-230/460V | 56C | TEFC | 26 | Detailed information | LOGIN TO SEE |
